CCS压力开关|差压开关|温度开关
>
CCS压力开关pressure switch
CCS压力开关611G系列
CCS 压力开关 611G 611GE 系列611G接口尺寸1/4"接口材料合金隔膜材料聚丁钠橡胶最大允许压力(MPa)设定压力范围(MPa)压力开关型号SPDTDPDT1.7240.010~0.078611G8001611GM80013.4480.083~0.193611G8003611GM80033.4480.208~0.462611G8005611GM80053.4480.483
详细介绍
CCS 压力开关 611G 611GE 系列
611G
接口尺寸
1/4"
接口材料
合金
隔膜材料
聚丁钠橡胶
最大允许压力(MPa)
设定压力范围(MPa)
压力开关型号
SPDT
DPDT
1.724
0.010~0.078
611G8001
611GM8001
3.448
0.083~0.193
611G8003
611GM8003
3.448
0.208~0.462
611G8005
611GM8005
3.448
0.483~1.193
611G8007
611GM8007
611GE
接口尺寸
1/4"
接口材料
合金
隔膜材料
聚丁钠橡胶
最大允许压力(MPa)
设定压力范围(MPa)
压 力 开 关 型 号
SPDT
DPDT
1.724
0.010~0.078
611GE8001
611GEM8001
3.448
0.083~0.193
611GE8003
611GEM8003
3.448
0.208~0.462
611GE8005
611GEM8005
3.448
0.483~1.193
611GE8007
611GEM8007
接点容量
电压
电流
SPDT
DPDT
Res
Res
125AC-50/60Hz
11
11
250AC-50/60Hz
11
11
30DC
5
5
125DC
5
5
Highly reliable devices utilizing the CCS Dual-Snap® Belleville disc spring principle pioneered by CCS’ engineers.
Engineering based on aerospace technology.
Rigid, compact and externally adjustable for factory setting or convenient field set point adjustment.
Repeatable and stable set points.
Vibration and shock resistant.
High cycle life.
High over-pressure capability.
Various options for wetted materials and electrical ratings to meet a wide range of application requirements and media compatibility.
SERIES:
611G*
611GZ*
611V*
SET POINT RANGE:
GAGE PRESSURE:
.75 to 180 PSIG
.052 to 12.4 bar
5.17 to 1241 kPa
VACUUM:
1.5 to 28.5” Hg
38 to 724 mm Hg
