+GF + 电磁流量计Electromagnetic Flowmeter 159001

+GF + 电磁流量计Electromagnetic Flowmeter 159001

变送器使用和安装都很方便,没有可动部件, 不需维护;可靠性和性价比高的通用型流量变送器。兼容性:可带Signet5075

5500 , 5600 , 8550, 8900或直接输出.

技术规格:

外壳: PBT

防护等级: NEMA4X/IP65 (当正确安装)

接线要求:

4到20mA : 24VDC+10%

频率: 5到24VDC

S3L : 4.5到6.5VDC

极性颠倒和短路保护

性能

管道尺寸范围: -P0, -T0: 1/2到4in

-P1,-T1: 5到8in

流量范围:0.05-10m/s

线性: +/-(读数的1%+ *大量程的0.1%)

可重复性:读数的+/-0.5%@25°C

*小电导: 20μS/cm

输出规格:

电流输出( 4到20mA )

两线制-定向输出

回路精度: *大误差32 μA

(@25%C@ 24VDC)

温度漂移: +/- μA*大每°Cquotation njxj888@163.com

+GF+Electromagnetic Flowmeter 159001

The transmitter is easy to use and install, with no movable parts and no need for maintenance; A universal flow transmitter with high reliability and cost-effectiveness. Compatibility: can come with Signet5075

5500, 5600, 8550, 8900 or direct output

Technical specifications:

Shell: PBT

Protection level: NEMA4X/IP65 (when installed correctly)

Wiring requirements:

4 to 20mA: 24VDC+10%

Frequency: 5 to 24VDC

S3L: 4.5 to 6.5VDC

Polarity reversal and short circuit protection

performance
